Č. 15-Nitronic 50 XM-19 Šestihranný šroub DIN931 UNS S20910

Specifikace


xm19/s20910 hex bolt din931 m36
1.material:xm19/s20910
2.Finish:nickel
3.ISO9001

xm19/s20910 hex bolt din931 m36

1. xm19/s20910 stud bolts

2.Size: M4-M100(1/4-4 inch) 3.Standard: ANSI ,DIN,ASME,ASTM 4.Material: inconel ,S32750,S32760,S31803,904L,Incoloy 925, ASTM A453- 660A,Inconel 625, Hastelly C-22, Monel 400, Monel K-500, Nimonic 80A, Zr 702, Zr 705, 254SMO, etc.

Packing:Suitable for exporting


XM-19 Stainless Steel, a highly fabricable, highly weldable, nitrogen strengthened, austenitic stainless steel, provides twice the yield strength of stainless steel type 316 and a resistance to corrosion equivalent to type 316. Even after extreme forming, XM-19 Stainless Steel stays non-magnetic. Due to all these advantages, it is often used in boat shafting, marine hardware, pumps, valves, and fasteners. The machinability of XM-19 Stainless Steel is comparable to that of alloy 316 or 317. It is formable, but there will be more springback with XM-19 than with other austenitic stainless steels. To achieve maximum hardness, use cold working. Because of XM-19's high tendency toward work hardening, process anneal the work piece after forming to relieve stress.

Chemie


Chemical Requirements

Ni

Cr

Po

Mn

C

Si

Fe

Max

13.5

23.5

3.00

6.0

0.06

1.00

Bal

Min

11.5

20.5

1.50

4.0

Tensile Data


Mechanical Property Requirements

Ultimate Tensile

Yield Strength (0.2% OS)

Elong.

R/A

Tvrdost

Min

100 KSi

55 KSi

35%

55%

Max

293

Min

690 MPa

380 MPa

Max

There are other high strength properties available for sizes of bar, wire, sheet and plate. Inquire with a sales associate at High Performance Alloys for more information. See bulletin, or brochure on the material (above) for a quick overview.

Specifikace


Formulář

Standard

Metal Type

UNSS20910

Bar

ASTM A193 ASTM A194 ASTM A276 ASTM A479 AMS 5764

Drát

List

ASTM A240 AMS 5861

Deska

ASTM A240 AMS 5861

Kování

Kování

ASTM A182 ASTM A193 ASTM A 194 ASTM A276 ASTM A479 AMS 5764

Weld Wire

A5.9 ER209

Din

1.4565

Rychlé informace


Místo původu: Jiangsu, Čína (pevnina)
Název značky: HPF, QFC
Číslo modelu: M3-M48
name: xm19/s20910 stud bolts m24 all lengh
material: Nitronic 50
Standard: USS,DIN,JIS,GB,BS




, , , , ,
